Copper Rod Cold Rolling Mill
Brief Introduction
Copper Rod Cold rolling mill
The unit is divided into 2-roller copper rolling mill and 3-roller copper rolling mill, which used in continuous rolling of copper and copper alloy rod. It has high efficiency, energy saving, refining, and strengthen the copper rod crystal organization and etc.
2-roller copper rolling mill
Under the effect of two rollers, the copper rod is always in up and down pressing stress state, which restrains the free spread of copper rod. Rolled pieces are without torsion. The variable frequency speed regulating device reduces power consumption and make it easy to operate.
3-roller copper rolling mill
It is a Y type 3-roll continuous rolling mill. Three rollers arranged in "Y" shape.Under the action of the three rolls, the rods in the deformation process is always in three-dimensional stress state, restraining the rods spreading freely, rolling pieces are without torsion.
Detailed Information
2-Roller Copper Rolling Mill
1. The main motor of rolling mill and the take-up machine both adopt frequency conversion stepless speed regulation.
2. The producing efficiency is high because oval and round rolling passes roll the workpieces alternately.
3-Roller Copper Rolling Mill
1. The structure of equipment is compact with small size and small floor space.
2. The density and conductivity of the finished rolling product is better than drawing.
3. Without wear mold and grind head.
4. Continuous line during rolling.
5. If rolling and stretching are in the same compression ratio, rolling has less work hardening and easily to control which is in favor to further stretch processing.
6. In the process with high total compression rate, rolling deformation can be extended to the center rod.
7. The stomata and tiny cracks of casting rods can be eliminated in the rolling process
