Continuous Vertical Enameling Machine
Brief Introduction
The main function of the vertical enameling machine is to evenly coat the insulating varnish on the surface of the conductor to form a uniform and smooth insulating layer, thereby protecting the conductor and improving its electrical and mechanical properties. Specifically, the vertical enameling machine plays a vital role in the manufacturing process of wires and cables.
Detailed Information
Features
1. Space saving: vertical enameling machines generally have a small footprint
2. High production efficiency: can quickly and accurately coat enameled wires, thereby increasing production efficiency, reducing production time, and increasing output
3. High degree of automation: equipped with an automated control system that can automatically adjust parameters such as line speed, tension, and coating thickness, reducing the need for manual operation and improving production consistency and quality
4. Good environmental performance: small packaging machines use high-quality stainless steel (SUS304) to weld to form green and environmentally friendly packaging, which meets the requirements of environmental protection policies
Technical Parameters
| Wire gauge range | Φ: 0.60mm-1.50mm | Pay-off method | Rolling |
| Number of production heads | 36 (18+18) | Retracting method | Single-axis horizontal take-up |
| Number of paint passes | 6 | Painting method | Felt/mold |
| Wire spacing | 11.5mm | Power supply voltage | 3X380V50HZ |
| Wire speed range | 0-50m/min | Total power | 300KW |
| Wire take-up reel | PT15-PT25 | Daily power consumption | 800kw.h around |
| Wire pay-off reel | Φ: 400mm-500 mm |
